Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Output 15A / 7.2V (MAX 108W)
BEC Data 5V 2A
Peak / continuous 20A / 15A
P.W.M 9.5 kHz
weight 17.9g
Dimension(L×B×Hmm) 28×25×11
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Output 25A / 7.2V (MAX 180W)
BEC Data 5V 2A
Peak / continuous 30A / 25A
P.W.M 9.5 kHz
weight 31g
Dimension(L×B×Hmm) 51×25.5×11
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Output 25A / 7.2V (MAX 180W)
BEC Data 5V 2A
Peak / continuous 30A / 25A
P.W.M 9.5 kHz
weight 31g
Dimension(L×B×Hmm) 40×28.8×30
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Output 35A / 7.2V (MAX 260W)
BEC Data 5V 2A
Peak / continuous 100A / 35A
P.W.M 9.5 kHz
weight 50g
Dimension(L×B×Hmm) 32×38×19
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Output 35A / 7.2V (MAX 260W)
BEC Data 6V 2A
Peak / continuous 100A / 35A
P.W.M 9.5 kHz
weight 50g
Dimension(L×B×Hmm) 32×38×19
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Output 45A / 7.2V (MAX 324W)
BEC Data 5V 2A
Peak / continuous 90A / 54A
P.W.M 9.5 kHz
weight 66g(with wire&connector&fan)
Dimension
(L×B×Hmm)		 25×51×13.5
　

Manual
Ch
En
Input 7.2V~14.8V
Output 75A / 7.2V (MAX 540W)
BEC Data 5V 1A
Peak / continuous 225 / 150A
P.W.M 9.5 kHz
weight 149g
Dimension
(L×B×H1×H2mm)		 45×44.7×22×42.9
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Output 75A / 7.2V (MAX 540W)
BEC Data 5V 2A
Peak / continuous 225A / 150A
P.W.M 9.5 kHz
weight 53.6g
Dimension
(L×B×H1×H2mm)		 37×28.8×36.5
　

Manual
Ch
En
Input 7.2V~14.8V
Output 75A / 7.4V (MAX 864W)
BEC Data 5V 2A
Peak / continuous 225A / 150A
P.W.M 9.5 kHz
weight 150g
Dimension
(L×B×Hmm)		 45×44.7×22x50.8
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Motor limit over 7.5R/7.4V(2S)
BEC Data 6V 2A
weight 65 g
Dimension
(L×B×Hmm)		 44.3×30×24.7
　

Manual
Ch
En
Input 7.4V(LI-PO) 14.8V(LI-PO)
Motor limit

over 4.5R/7.4V(2S)

 2000KV/14.8V(4S)
BEC Data 6V 2A
weight 165 g
Dimension
(L×B×Hmm)		 65.5×47.4×41.9
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Motor limit over 4600KV/7.4V(2S)
BEC Data 6V 2A
weight 62 g
Dimension
(L×B×Hmm)		 32.4×49.2×26.3
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Motor limit over 3500KV/7.4V(2S)
BEC Data 6V 2A
weight 50 g
Dimension
(L×B×Hmm)		 38×32×19
　

Manual
Ch
En
Input 7.2V(NI-CD/MH)
7.4V(LI-PO) 6.6V(LI-FE)
Motor limit over 5.5R/7.4V(2S)
BEC Data 6V 2A
weight 65 g
Dimension
(L×B×Hmm)		 44.3×30×24.7
　
　
　
　
